| 規格： |
|
|
線電壓調整
|
< =0.02% + 3mV |
|
解載電壓調整
|
< =0.02% + 3mV |
|
回復時間
|
< =100ms Typical |
|
漣波電壓
|
< =2mVrms |
|
溫度系數
|
300PPM/℃ (0℃ to 40℃) |
|
|
電壓范圍
|
0-63V |
|
電壓表分辨率
|
100mV |
|
電壓表準確度
|
+/- 0.5% rdg + 2 digits |
|
電流范圍
|
0 to 3.1A |
|
電流表分辨率
|
10mA |
|
電流表準確度
|
±0.5%rdg + 2 digits |
|
|
Adjustable Current Limits
|
0 to 3A |
|
線電流調整
|
< =0.2% + 3mA |
|
負載電流調整
|
＜ =0.2% + 3mA |
|
漣波
|
＜ =3mA
顯示器: 3 1/2 digit LCD |
|
|
電源
|
110/230VAC +-10%, 50/60Hz |
|
消耗功率
|
300W |
|
操作及儲存溫濕度
|
0 ℃ to 40 ℃ (32 ℉ to 104 ℉ )
-10 ℃ to 70 ℃ (14 ℉ to 158 ℉ ) |
|
顯示器
|
3 1/2 digit LCD |
|
尺寸
|
190mm x 115mm x 332mm (H x W x D) |
|
重量
|
10kgs |
|
Power Cord Plug
|
Type
Please describe in your order form.
|
|
